CT520

PROFESSIONAL OUTDOOR
EQUIPMENT MANUFACTURER

We always devote to protect blue planet


Product Description

   Category:        Aluminium Hull

   Tube material:  PVC from Mehler, Hypalon from Orca

   Model Range:   CT340/ CT360/ CT400/ CT420/ CT460/ CT500 CT520 / CT560/ CT620/ CT660/ CT680


   Standard Equipments:

   * BowStep/Cleat

   * Bow locker

   * Bow cushion

   * Integrated Fuel Tank

   * Tow bridle points

    * Seat&Cushion

    * Steering console with wind shield

   * Lifting points and towing eyes

   * Brushed foam teak finish deck

   * Heavy duty rubbing strake

   * Full length keel guard

   * Foot pump, oars, repair kit


   Optional Equipments:

   * Boat canopy/Bimini Top

   * Roll bar



   Specification of CAPTAIN Series:

Model CT500 CT520 CT560 CT620 CT660 CT680

Overall Length(cm)

500 520 560 620 660 680

Overall Width(cm)

222 226 234 248 248 248

Inside Length(cm)

400 420 450 530 560 590

Inside Width(cm)

120 125 130 140 140 140

Tube Diameter(cm)

51 52 52 54 54 54

Max. Load(kg)

1000 1050 1100 1400 1480 1550

Max. Person

10 10 10 14 15 16

Max. Power(hp)

100 100 115 130 150 150

Net Weight(kg)

360 380 440 520 660 600

No. of Chamber

5 5 5 6 6 6
Fuel Tank Volume(L) 80 90 100 130 140 140
Thickness(mm) 4 4 4 4 4 4
Dead Rise 24° 24° 24° 24° 24° 24°
Transom Height(cm) 53 53 64 64 64 64
Shaft L L XL XL XL XL
